Ronen® Fully Automatic Threading Machine is highly favored by many suppliers as it is the ideal choice for industrial threading. Ensuring precise threading thanks to its precision mechanical structure, it is compatible with a wide range of pipe sizes and offers easy operation.
The Fully Automatic Threading Machine has diverse functions. In addition to basic thread processing, it can also perform pipe cutting, chamfering and other operations, realizing integrated processing and improving production scheduling efficiency.
Fully Automatic Threading Machine has strong compatibility and supports multiple thread standards. It can be quickly switched by replacing molds of different specifications without large-scale adjustments to the equipment to adapt to diverse production needs.
The Machine is equipped with a digital control panel that allows precise setting of parameters such as thread depth and pitch, and supports a one-touch reset function. It also features anti-slip handrails on both sides of the machine body and universal wheels with brakes at the bottom, making it easy to move and fix.
Fully Automatic Threading Machine is applicable to a wide range of industries, including pipe installation in the construction and building materials industry, parts processing in the machinery manufacturing industry, pipeline laying in the petrochemical industry, and water supply and drainage pipeline construction in the municipal engineering industry.
The core selling point of the Fully Automatic Threading Machine is its combination of high efficiency and durability. Equipped with a high-power motor, it can complete 8-12 standard threads per minute. At the same time, the cutting tool is made of tungsten steel alloy, with a service life of more than 5,000 times, which greatly reduces the frequency of consumable replacement.
| Model | 3H30A/B | 4H45A/B | 4H55A/B | 6H55A/B | 6H70B | 6H105B | 6H40BL | 8H80B | 8H105B |
| Diameter Range(mm) | 2-3.5 | 2.5-4 | 3-5 | 4-6 | 4-6 | 4-8 | 4-8 | 5-8 | 5-10 |
| Blank Length Max(mm) | 30 | 45 | 55 | 50 | 70/85 | 105/125 | 40 | 80 | 105/125 |
| Max Thread Length(mm) | 30 | 40 | 50 | 45 | 70 | 100 | 40 | 75 | 100 |
| Capacity(pcs/min) | 230-270 | 180-230 | 160-200 | 120-160 | 120-160 | 120-140 | 60 | 90-120 | 90-120 |
| Main Motor(KW) | 1.5 | 2.2 | 3 | 4 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 |
| Height Of Die Pocker(mm) | 25*30*70/80 | 25*45*76/90 | 25*55*85/100 | 25*50*110/125 | 25*70*110/125 | 25*105*110/125 | 40*40*235/260 | 30*80*150/170 | 30*105*150/170 |
| Oil Motor(KW) | 0.18 |
0.18 |
0.18 |
0.18 |
0.18 |
0.18 |
0.18 |
0.37 | 0.37 |
| Feed Motor(KW) | 0.37 | 0.4 | 0.5 | 0.37 | 0.6 | 0.6 | 0.5 | 0.6 | 0.6 |
| Packing Volume(cm) | 150*91*140 | 170*125*150 | 172*130*150 | 185*125*150 | 195*145*160 | 200*160*160 | 234*140*160 | 245*150*160 | 244*170*160 |
| NW(KG) | 570 | 850 | 1170 | 1400 | 1500 | 1700 | 2500 | 3100 | 3200 |
