Looking for efficient bolt manufacturing equipment? Ronen®, a trusted manufacturer, offers the ideal choice with its Bolt Making Assembly Making Machine. This machine integrates feeding, forming, and testing functions, enabling rapid production of a wide range of standard and non-standard bolts.
Bolt Making Assembly Making Machine integrates multiple production processes, starting from raw material processing, through cold heading, thread rolling, testing, assembly and other links, and ultimately outputs finished bolts that meet standards.
The working principle of the Bolt Making Assembly Making Machine is a combination of automated control and precision mechanical transmission: after the raw materials enter the equipment through the feeding mechanism, they are first forged into the prototype of the bolt by a cold heading die, and then the threads are processed by a thread rolling device. Then, the assembly module is equipped with accessories as needed to complete the assembly. Finally, qualified products are screened by the testing device to realize full process automation.
This Machine uses high-strength alloy molds with strong wear resistance and extended service life; the equipment is equipped with intelligent sensors that can monitor pressure, temperature and other parameters in real time during the production process.
Bolt Making Assembly Making Machine is widely used in automobile manufacturing, construction and building materials, mechanical equipment, power engineering, rail transportation and other industries.
| Model | Diameter Range mm | Blank Length Max mm | Max Thread Length mm | Capacity pcs/min | Main Motor KW | Height Of Diepocket mm | Oil Motor KW | Feed Motor KW | Net Weight KG |
| 3H30 | 2-3.5 | 30 | 30 | 230-270 | 1.5 | 25*30*70/80 | 0.18 | 0.37 | 570 |
| 4H45 | 2.5-4 | 45 | 40 | 180-230 | 2.2 | 25*45*76/90 | 0.18 | 0.4 | 850 |
| 4H55 | 3-5 | 55 | 50 | 160-200 | 3 | 25*55*85/100 | 0.18 | 0.5 | 1170 |
| 6H55 | 4-6 | 50 | 45 | 120-160 | 4 | 25*50*110/125 | 0.18 | 0.37 | 1400 |
| 6H70 | 4-6 | 70/85 | 70 | 120-160 | 5.5 | 25*70*110/125 | 0.18 | 0.6 | 1500 |
| 6H105 | 4-8 | 105/125 | 100 | 120-140 | 5.5 | 25*105*110/125 |
0.18 |
0.6 | 1700 |
| 6H40 | 4-8 | 40 | 40 | 60 | 5.5 | 40*40*235/260 |
0.18 |
0.5 | 2500 |
| 8H80 | 5-8 | 80 | 75 | 90-120 | 7.5 | 30*80*150/170 |
0.37 |
0.6 | 3100 |
| 8H105 | 5-10 | 105/125 | 100 | 90-120 | 7.5 | 30*105*150/170 |
0.37 |
0.6 | 3200 |
| 8H150 | 5-10 | 150/200 | 150 | 90-110 | 11 | 30*150*150/170 |
0.37 |
0.8 |
3300 |
| 10H105 |
6-10 |
105/125 | 100 | 90-110 | 11 | 30*105*150/170 |
0.37 |
0.8 |
3500 |
| 12H150 |
8-14 |
150/200 | 150 | 75 | 15 |
40*150*190/210 |
0.37 |
0.8 |
4400 |
| 12TH150 |
8-14 |
150/200 | 150 | 75 | 15 |
40*150*190/210 |
0.37 |
0.8 |
5200 |
| 14H105 |
8-14 |
105 | 100 | 75 | 15 | 40*150*190/210 | 0.37 | 0.8 | 4600 |
| 16H150 | 10-18 |
150/250 |
150 | 45-50 | 22 | 45*150*235/260 | 0.36 | 1 | 12300 |
| 20H150 | 16-22 |
150/250 |
150 | 35-42 | 30 | 50*150*285/310 | 0.36 | 2 | 14700 |
| 24H150 | 20-25 | 150/250 | 150 | 42 | 37 | 50*150*380/420 | 0.36 | 4 | 19000 |
The Bolt Making Assembly Making Machine is characterized by high efficiency and productivity, controllable precision, convenient operation, and strong adaptability: its efficiency far exceeds that of traditional equipment; its digital control has high precision; and its operation interface is simple.
