Ronen®Stainless Steel Nut Former is easy to operate and can automatically feed nuts when processing them, saving manpower. It is easy to purchase, and there are discounts for bulk orders. The repurchase rate is high and the brand has a good reputation.
Stainless Steel Nut Former uses a motor to drive the die to punch and process the raw materials into nuts that meet the specifications. The entire process is automated, with feeding, forming, and discharging being carried out continuously without much manual intervention.
Product parameters
| Model | Unit | WH-NF 11B-6S | WN-NF 14B-6S | WH-NF 17B-6S | WH-NF 19B-6S | WH-NF 24B-6S |
| Forging Station | NO | 6 | 6 | 6 | 6 | 6 |
| Max Feeding Length | MM | 18 | 15 | 17 | 19 | 24 |
| Suitable Hex Nut | DIN | M3-M6 | M6-M10 | M8-M12 | M8-M14 | M10-M18 |
| Cut-Off Dia | mm | 11 | 16 | 17 | 19 | 24 |
| Speed Range | Pcs/min | 120-240 | 120-180 | 150 | 60-100 | 60-90 |
| Dies Pitch | MM | 50 | 60 | 70 | 80 | 100 |
| Forging Pqwer | Ton | 60 | 90 | 110 | 135 | 230 |
| Main Motor | HP | 15 | 20 | 30 | 50 | 75 |
| Lubrication Motor | HP | 1.5 | 1.5 | 1.5 | 1.5 3 | 1.5 3 |
| Installed Quantity | Set | (1) | (2) | (1)(1) |
(1)(1) |
(1)(1) |
| Lubricant | L | 700 | 1000 | 1200 | 1200 | 1100 |
| Approx Weight | Ton | 4.5 | 8 | 11 | 14 | 25 |
The working principle of Stainless Steel Nut Former is that the motor drives the internal mold to operate. Put the metal raw material into the feed port, the machine will automatically send the raw material between the molds, and then the mold will quickly punch, press the raw material into the shape of a nut, and extrude the thread at the same time.
Stainless Steel Nut Former is very durable. With normal use and few bumps, it will last for a few years without any problems. Maintenance is also simple. Just wipe it regularly and tighten the screws. You don’t need to spend too much effort on maintenance.
The machine is not too big, and can be placed in a small workshop or a corner of a store, making it easy to move. The feed port is well designed and highly automated. The buttons on the machine are clearly marked, and you can understand how to adjust the size and start and stop the machine at a glance, without having to study the instructions for a long time.
Stainless Steel Nut Former is highly adaptable. Whether it is carbon steel, stainless steel or alloy material, you only need to replace the corresponding mold to continue processing. According to different product models, you can also adjust parameters and replace molds at any time. It is easy to use and does not require re-purchase of equipment.
