Ronen® Threading Rolling Machine are the ideal choice for thread processing, capable of efficiently completing various threading operations. For suppliers seeking stable and reliable devices or planning to upgrade their production lines, this machine can meet your needs.
Thread Rolling Machine 2 Roll Type features an innovative design that adapts to thread processing on a variety of materials, offering strong stability and a low failure rate. Its intelligent control system simplifies operating procedures, saves labor costs, and enables efficient production.
| Model | 3H30A/B | 4H45A/B | 4H55A/B | 6H55A/B | 6H70B | 6H105B | 6H40BL | 8H80B | 8H105B |
| Diameter Range(mm) | 2-3.5 | 2.5-4 | 3-5 | 4-6 | 4-6 | 4-8 | 4-8 | 5-8 | 5-10 |
| Blank Length Max(mm) | 30 | 45 | 55 | 50 | 70/85 | 105/125 | 40 | 80 | 105/125 |
| Max Thread Length(mm) | 30 | 40 | 50 | 45 | 70 | 100 | 40 | 75 | 100 |
| Capacity(pcs/min) | 230-270 | 180-230 | 160-200 | 120-160 | 120-160 | 120-140 | 60 | 90-120 | 90-120 |
| Main Motor(KW) | 1.5 | 2.2 | 3 | 4 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 |
| Height Of Die Pocket(mm) | 25*30*70/80 | 25*45*76/90 | 25*55*85/100 | 25*50*110/125 | 25*70*110/125 | 25*105*110/125 | 40*40*235/260 | 30*80*150/170 | 30*105*150/170 |
| Oil Motor(KW) | 0.18 |
0.18 |
0.18 |
0.18 |
0.18 |
0.18 |
0.18 |
0.37 | 0.37 |
| Feed Motor(KW) | 0.37 | 0.4 | 0.5 | 0.37 | 0.6 | 0.6 | 0.5 | 0.6 | 0.6 |
| Packing Volume(cm) | 150*91*140 | 170*125*150 | 172*130*150 | 185*125*150 | 195*145*160 | 200*160*160 | 234*140*160 | 245*150*160 | 244*170*160 |
| NW(KG) | 570 | 850 | 1170 | 1400 | 1500 | 1700 | 2500 | 3100 | 3200 |
Thread Rolling Machine 2 Roll Type forms precise threads on the surface of a workpiece through rolling, without cutting material. Instead, it relies on a die to apply pressure to the workpiece, causing it to plastically deform, thereby producing threads. This is more efficient and material-saving than traditional cutting methods.
Our machine is meticulously designed with meticulous attention to detail: it utilizes high-strength alloy molds for superior wear resistance and a service life of tens of thousands of cycles; it is equipped with a continuously variable speed system that adjusts the rolling speed according to the workpiece material; it features automatic feeding and unloading devices to reduce manual intervention; and protective devices are installed in key areas to ensure safe operation.
The application scenarios of Thread Rolling Machine 2 Roll Type include batch thread processing lines in large factories, customized threaded parts production workshops of small and medium-sized enterprises, and professional workshops that provide supporting processing services for automotive parts and mechanical parts manufacturers.
The core selling points of the Thread Rolling Machine 2 Roll Type are efficiency and quality. Its thread processing speed far exceeds that of cutting equipment, and a single machine can process thousands of workpieces per hour. In addition, the threads processed by the Thread Rolling Machine 2 Roll Type are smooth and have high strength, meeting the strict requirements of high-precision processing.
